CP1008 Loading Power 75kw Hammer Crusher

About CP1008 Loading Power 75kw Hammer Crusher

Hammer crusher

The hammer crusher is suitable for crushing coarse, medium and medium-hard brittle and abrasive materials such as limestone, coal gangue, gypsum and shale with a compressive strength of less than 180 MPa (not exceeding 100 MPa) and a water content of less than 15%. It is suitable for crushing medium hardness materials in industrial sectors such as cement, chemical, electric power and metallurgy. The material with a maximum particle size of 600-1800mm can be directly crushed to 25mm or less. It is also used to crush waste of wood, paper and broken asbestos cement with strong fiber structure, elasticity and toughness to recover asbestos fiber and so on.

Hammer crusher is currently divided into two types: heavy and light. The ring hammer type coal crusher (light ring hammer crusher) is suitable for the crushing of Mohs hardness secondary materials, using broken coal ring hammer. The ring hammer crusher (heavy ring hammer crusher) is suitable for the crushing of brittle materials with a Mohs hardness of less than five grades, using a gra vel ring hammer. The quality of the gra vel ring hammer is greater than the mass of the broken coal ring hammer, thereby increasing the impact force of the ring hammer and achieving the purpose of crushing the ore.

The hammer crusher is composed of a hammer crushing case body, a rotor, a hammer head, a counter lining plate, a sieve plate and the like.
The hammer crusher is composed of an upper casing, a lower casing, a transmission member, a sieve plate member and the like.
The main working component is a rotor with a hammer (also known as a hammer). The rotor consists of a main shaft, a disc, a pin and a hammer. The motor drives the rotor to rotate at high speed in the crushing chamber. The material is fed into the machine from the upper feed port, and is crushed by the impact, shearing and grinding action of the high-speed moving hammer. In the lower part of the rotor, there is no sieve plate, and the size of the pulverized material smaller than the mesh size is discharged through the sieve plate, and the coarse-grained grade larger than the mesh size is retained on the sieve plate and continues to be struck and grounded by the hammer, and finally discharged through the sieve plate outside the machine.

Performance characteristics
1. Advanced design technology, strong structure and impact resistance.
2. The material size is large, the yield is high, and the grain shape is good.
3. Super broken, thick, medium, fine broken one step in place.
4. The annual output is increased by 30%, and the needle-like (powdered) is less than 20%, which is more energy-saving.
5. The hammer head and sieve plate are made of chrome-manganese alloy material, which has stronger impact resistance and wear resistance.
6. Compact structure, reasonable layout, convenient installation, good maintainability and easy operation.
7. Saving process layout space, with special structural features, such as large breaking ratio of material crushing.
8. Excellent adaptability to cement production process layout.

Foreign shale is different, there are many clays, and the crusher is not used much.
